MICRA 100 · Stadiums and arenas
MICRA 100 is in the Stadiums and arenas range of the BoxTech catalogue. Centres and tip-up depth are checked on the drawing before the count is approved. The photograph identifies the form.
Put this model in the note| Family | Stadiums and arenas |
|---|---|
| Planning centre | 500 mm |
Technical specifications
Engineering data for design, planning and procurement. Published values only; unavailable fields are left blank.
Original dimensioned technical drawing – click to enlarge
| Seat centres | 48-52 cm |
|---|---|
| Overall depth | 53 cm |
| Overall height | 11 cm |
| Weight | 15.00 Kg |
| Shipping volume | 0.090 m³ |
| Backrest | Manufactured over – flat MDF board, on which an open cell polyurethane foam block upholstered by means of – fabric cover is fixed. All this structure is protected by means of – steel strip in the low part. No need of any spring for the folding of the backrest, thus achieving – precise, sound, reliable, noiseless and maintenance-free structure. Foam density, 40 Kg/m³ |
|---|---|
| Seat | Manufactured over – flat MDF board, on which an open cell polyurethane foam block upholstered by means of – fabric cover is fixed. Fixed to the grandstand floor in – discreet way, thus keeping completely concealed from view. Foam density, 40 Kg/m³ |
| Side panels | Tip-up folding system in carbon steel, finish in epoxy paint. |
| Armrest | Optionally in rounded texturized injected polypropylene. |
| Foam density | Seat: 40 kg/m³ · Backrest: 40 kg/m³ |
7 fabric ranges
Design tool
Elevations dimensioned from this seat's specification, plus a hall layout calculator with live plan and sightline section.
Schematic drawing – not to scale
Results are estimates for preliminary planning and must be verified against local fire, safety and egress codes.
